PostgreSQL - Tutorial - How to Migrate an On-Premises Database to Cloud Databases

Stephanie R.
Updated

Learn the procedure to migrate a PostgreSQL instance running on-premises to OVHcloud Managed Databases (also called Cloud Databases) for PostgreSQL.



Requirements

  • a Public Cloud project in your OVHcloud account
  • a PostgreSQL database running on-premises (the "source" instance)
  • a PostgreSQL database running on OVHcloud Cloud Databases (the "target" instance)
  • a PostgreSQL client that can connect to both database instances, source, and target
  • access to the OVHcloud Control Panel

These guides can help you to meet these requirements:



Considerations

  • This document outlines an offline migration path for your database, which means you will have to suspend all the writes from your application for the duration of the migration. Ensure you plan sufficient downtime to carry out all the migration tasks.
  • Ensure the source and destination PostgreSQL versions match.
  • Ensure you have good enough bandwidth between the client machine and both source and destination databases.
  • Ensure you choose a Database plan with appropriate compute, storage, and memory resources.



Procedure

Step 1: Stop writing to the source database

Ensure client applications stop all write activity on the source database side. Depending on your system, this might entail letting your customers know in advance about unavailability, stopping other upstream applications, or some other administrative, operations, or development tasks.



Step 2: Export the schema

Use the pg_dump command to export the database schema to the client machine, as an SQL plaintext file:

$ pg_dump --file "path/to/dump.sql" --host "<on-prem hostname>" --port "<write port>" \
    --username "postgres" --verbose --format=p --schema-only "database-name"



Step 3: Export the data

Use the pg_dump command to export the database data to the client machine, in a .tar archive file:

NOTE: This command will automatically apply to the default database. To specify a different database, insert --dbname=<database name" into the command below after "--username "postgres".
$ pg_dump --file "path/to/dump.tar" --host "<on-prem hostname>" --port "<write port>" \
    --no-owner --username "postgres" --verbose --format=t --blobs --encoding "UTF8"

Exporting the full dataset may take time depending on the size of the database and available bandwidth.



Step 4: Edit the schema

Since you won't have access to superuser privilege (usually named postgres) on the destination database, you need to replace references to that role in the schema dump file with another role, either avnadmin, the initial admin user of your managed database, or another user you'd have created beforehand.

Open the schema dump file with a text editor and search for lines such as:

ALTER TABLE public.<table> OWNER TO postgres;

Edit it so that it reads:

ALTER TABLE public.<table> OWNER TO avnadmin;

Then, search the schema dump file for anything that is not compatible with the OVHcloud Public Cloud Databases offer. Review PostgreSQL - Capabilities and Limitations to learn about what the destination database supports.

Pay particular attention to anything related to extensions, users, roles, and schemas. For example, if you installed any third-party extensions, you'll need to remove them as extensions will be handled differently going forward (check the list of supported extensions here: PostgreSQL - Available extensions).



Step 5: Import the schema

Use the following psql command to restore the schema on the destination:

$ psql -v ON_ERROR_STOP=1 -h postgresql-xxxxxxxx.database.cloud.ovh.us -p <port> \
    -d defaultdb -U avnadmin < path/to/the/dump.sql

This step should be completed quickly.



Step 6: Verify the schema import

Connect to your database service to check if the schema restore was completed successfully:

$ psql "postgres://<username>:<password>@<hostname>:<port>/defaultdb?sslmode=require"

Check the table(s):

defaultdb=> \dt

Verify the schema:

defaultdb=> \d <tablename>
defaultdb=> select * from information_schema.columns;



Step 7: Import the data

Use the pg_restore command to restore the data:

$ pg_restore -d defaultdb -h <postgresql-xxxxxxxxx.database.cloud.ovh.us> -p <port> \
     --no-owner -U avnadmin --data-only path/to/the/dump.tar -v

As for the data export step, depending on the dataset size and the available bandwidth, the operation might take some time.
You can monitor the disk & network activity from the Metrics section of the DB service page in your OVHcloud Control Panel:




See, for example, the disk usage:




or the incoming network:




Step 8: Verify the data import

You can check if the data was migrated successfully by querying the destination database, e.g.:

defaultdb=> select pg_size_pretty(pg_total_relation_size('<tablename>'));
defaultdb=> select count(*) from <tablename>;



Step 9: Resume operations using the destination database

Once you verify that the database migration was successful, update client applications to have them connect to the destination database. You can now resume normal operations.



Go further

For more information and tutorials, please see our other Cloud Databases support guides or explore the guides for other OVHcloud products and services.
